A rugged all-in-one device for IoT connectivity, ideal for industrial or public use. Perfect for transportation projects or logistics, the LtAP LR8G LTE6 Kit combines:
- LoRa® connectivity, LTE, and GPS for maximum versatility
- Dual-chain 2.4 GHz WiFi for added flexibility
- A tough, robust enclosure built for industrial and mobile setups
- Mini SIM slot and a built-in modern LTE6 modem for fast and responsive mobile connectivity
- Enhanced 868MHz Rx sensitivity for effective long-range communication
- Many powering options, including automotive
- SMA female connectors for external antennas
The Things Network
Our products for LoRa® are ready to work with “The Things Network” – the famous open source infrastructure that provides free LoRa® network coverage and has tons of apps for your needs. With the help of “The Things Network” you can get started with the Internet-of-things within a day. And it is easily upgradable to enterprise-grade network “The Things Industries”.
The setup is so easy – anyone can learn it. No need to reinvent the wheel – join “The Things Network” to save time and energy with smart solutions!
Specifications
- Product codeLtAP-2HnD&FG621-EA&LR8G
- Suggested price$249.00
- ArchitectureMMIPS
- CPUMT7621AT
- CPU core count2
- CPU nominal frequency880 MHz
- CPU Threads count4
- RouterOS license4
- Operating SystemRouterOS v7
- Size of RAM128 MB
- Storage size16 MB
- Storage typeFLASH
- MTBFApproximately 200’000 hours at 25C
- Tested ambient temperature-40°C to 70°C
Powering
- Number of DC inputs3 (DC jack, PoE-IN, Automotive)
- DC jack input Voltage12-30 V
- Automotive input Voltage12-27 V
- Max power consumption24 W
- Max power consumption without attachments12 W
- PoE inPassive PoE
- Cooling typePassive
- PoE in input Voltage12-30 V
Mobile
- 3G CategoryR8 (42.2Mbps Downlink, 11.2Mbps Uplink)
- 3G bands1 (2100MHz)
3 (1800MHz)
5 (850MHz)
8 (900MHz)
- LTE Category6 (300Mbit/s Downlink, 50Mbit/s Uplink)
- MIMO DL2×2
- MIMO UL1×1
- LTE FDD bands1 (2100MHz)
3 (1800MHz)
5 (850MHz)
7 (2600MHz)
8 (900 MHz)
20 (800MHz)
28 (700MHz)
- LTE TDD bands38 (2600MHz)
40 (2300MHz)
41 (2500MHz)
- TAC86335904
Wireless specifications
- Wireless 2.4 GHz Max data rate300 Mbit/s
- Wireless 2.4 GHz Number of chains2
- Wireless 2.4 GHz standards802.11b/g/n
- Antenna gain dBi for 2.4 GHz2.5
- Wireless 2.4 GHz chip modelAR9342
- Wireless 2.4 GHz generationWi-Fi 4
Ethernet
- 10/100/1000 Ethernet ports1
Peripherals
- Number of SIM slots3 Modem (Mini SIM)
- MiniPCI-e slots2
- Serial console portRS232
- Number of USB ports1
- USB Power ResetYes
- USB slot typeUSB type A
- Max USB current (A)1
Other
- PCB temperature monitorYes
- Voltage MonitorYes
- GNSS standardsGPS
Certification & Approvals
- CertificationCE, EAC, ROHS
- IPX0
